The eOne-Sixty is the headline grabber of the Merida eBike range; for 3 generations it's been winning tests, gathering accolades and generally hogging the limelight!
The eOne-Forty shares exactly the same frame and design features but has different ride characteristics.
The shock stroke on the eOne-Forty is shorter, reducing rear travel to 133mm and creating a steeper seat angle. The shorter 140mm fork extends the reach, delivering a slightly steeper head angle. In combination these small changes make the eOne-Forty more agile and playful; a highly competent climber that's perfect for all day riding.
The mixed wheel size set up is carried over, to give the e-full suspension bikes precise steering, fantastic €˜rolling over obstacles €™ behaviour yet maximum traction, a 29er front wheel with a 2.5" tyre is combined with a 650B rear wheel, equipped with a slightly wider 2.6" tyre. The perfect combination of precision, playfulness and traction.
All eOne-Forty models use the powerful Shimano EP600 85NM motor and bigger 630Wh battery (with the exception of frame size - S which uses 504Wh).
Shimano's e-Tube app allows you to tailor power delivery to suit your riding style; you can set two profiles; one for shredding and one for cruising.
Frameset | Lite III - Hydroformed 6061 double butted aluminium with integrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8". |
---|---|
Fork | Marzocchi Z2 eMTB+; Air; 140mm travel; Tapered; 51mm fork offset. Max. tyre size: 29" x 2.6" |
Brakes | Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - stem length: 50mm all sizes; GoPro & Supernova mount |
Tyres | Merida Expert eTR; 780mm wide; 20mm rise |
Rear mech | Shimano Deore RDM5100 11 |
Wheelset | Merida Comp TR; 29mm inner rim width; Aluminium |
Headset | Merida-8152 |
Stem | Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - stem length: 50mm all sizes; GoPro & Supernova mount |
Handlebar | Merida Expert eTR; 780mm wide; 20mm rise |
Shifters | Shimano Deore M5100 and Shimano SL-MT500-IL dropper post lever |
Cassette | KMC e11S EPT |
Chain | Shimano M5100; 11-51 teeth; 11 speed |
Chainset | Shimano CRE70-B; 34 tooth chainring with Shimano FC-EM600; 165mm length crank |
Bottom bracket | Part of Shimano Steps motor |
Saddle | Merida Comp SL with V-mount |
Seat post | Merida Comp TR; 30.9mm diameter; in-line; Drop: 100mm (S), 125mm (M/L), 150mm (XL/XXL) |
Motor | Shimano EN806; 630Wh internal battery, Shimano Steps EP6; 85Nm |
Battery | 630Wh |
Rear shock | Suntour RS-Edge-TR-LO-R8-M6; lockout |
Tape grips | Merida Expert EC |
